General Specs |
| Width (in.) | 29.88 |
| Height (in.) | 5.5 |
| Duct Size (in.) | 7 |
| Depth (in.) | 17.5 |
| Color | Black |
| Positioning | Stationary |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Color Finish Name | Black on Black |
| Range Hood Type | Under Cabinet |
| ADA Compliant | No |
| Appliance Fit Width (in.) | 30 |
| Product Weight (lbs.) | 19 |
| Smart Compatible | No |
| Maximum CFM | 160 |
| Bulb Type | Incandescent |
| Grease Filter Type | Aluminum Mesh |
| Filter Indicator Light | No |
| Sones Rating | 6 |
| Fan Speed Options | 2 |
| Vent Location | Back |
| Ventilation Direction | Vertical |
| Shipping Width (in.) | 20.5 |
| Shipping Height (in.) | 8 |
| Voltage | 120 |
| Amp | 2.5 |
| Noise Level (Sones) | Standard - (High) |
| Ventilation Type | Ducted |
Construction |
| Exhaust: | Ducted |
| Chimney: | Fixed |
| Ductwork Type: | Vertical and Horizontal |
Dimensions |
| Shipping Weight: | 19 |
| Depth, Chimney : | 3.25 |
| Min Height Above Cooktop: | 30 |
Display |
| Controls: | Mechanical |
General Features |
| Filter Type: | 1 Dishwasher Safe Mesh Grease Filter |
| Pollutant Removal: | Externally Vented |
Other |
| Watts: | 60 |
| Considerations: | Use this unit only in the manner intended by the manufacturer. If youhave questions, contact the manufacturer at the address or telephonenumber listed in the warranty |
| Number of Lights: | 1 |
| Settings: | 2 |
| Air Mover Type(s): | Centrifugal |
| Air Mover(s) Speed: | 1 |
| Number of Air Movers: | 1 |
| Sones (Noise Level) Rating: | 7 |
Styling |
| Design: | Standard |
